REFL optical layout

Document #:

JGW-T1809238-v12

Document type:

T

Submitted by:

Naoki Aritomi

Updated by:

Kentaro Komori

Document Created:

05 Nov 2018, 19:33

Contents Revised:

10 Jun 2024, 19:03

Metadata Revised:

15 May 2025, 04:55

Abstract:

We made REFL optical layout.
Plots of beam radius for QPD and RFPD are also uploaded.

Files in Document:

• 20240610_KAGRA_REFL.png (548.8 kB)
• 20240610_KAGRA_REFL.svg (423.2 kB)

Topics:

• Detector:Interferometer
• Management
• Activity:KAGRA

Authors:

• Naoki Aritomi
• Yuta Michimura

Notes and Changes:

v12: This detail is klog29823.(https://klog.icrr.u-tokyo.ac.jp/osl/?r=29823)

Referenced by:

• JGW-T1910129: Conceptual Design of Optical Table Cover
• JGW-E1910506: Optical Layout of in-air detection tables
• JGW-T2416178: Rough Sketch of In-Vac PD and QPD Layout Plans

Approved for use in external presentations:

Unapproved
